24x7 Unmanned Weighbridge System
Automate truck turnaround time with HKDesk 24x7 Unmanned Weighbridge System. Combines fixed UHF RFID readers, PLC positioning interlocks, empty-scale interlocking, dual boom barriers, LED traffic signals, and audio voice prompts.
How Unmanned Weighing Works
Approach & UHF RFID Tag Read
Long-range UHF RFID reader detects vehicle tag (Ethernet/Serial) and matches registered truck master.
PLC Vehicle Position Check
Entry, middle, and exit sensors confirm the configured truck-position conditions before weighing continues.
Stable Weight & Camera Capture
Weight stabilizes above minimum threshold. Overview cameras capture gross/tare snapshots linked to ticket.
Automatic First/Second Selection
Software checks open RFID tickets and selects first weighment (gross/tare) or second weighment automatically.
Audio Prompt & Ticket Printing
Configured audio prompts guide the driver, and the approved weight-slip format can print automatically after saving.
Barrier Release & Empty Interlock
PLC lifts exit boom barrier. System resets after live weight returns to empty threshold (< 300-500 kg).
Integrated Hardware & Interlocks
UHF Long-Range RFID Reader
Ethernet or Serial fixed UHF readers with configurable 8 to 40 second transaction timeout.
PLC Positioning Interlocks
Industrial PLC controllers with optical position light sensors.
Dual Automatic Boom Barriers
PLC-controlled entry and exit boom barriers with automated position reset.
Red/Green LED Traffic Signals
Dual traffic lights guiding driver entry, weighing state, and exit.
Empty-Scale Interlocking
Prevents repeat weighing until live weight drops to zero/empty threshold for consecutive cycles.
Multi-Camera Evidence Capture
Supported IP cameras capture gross and tare overview snapshots linked to each ticket.
Unmanned Weighbridge FAQs
How does the PLC positioning sensor interlock work?
The PLC monitors entry, middle, and exit position sensors. The software permits the save workflow only when the configured position conditions indicate that the vehicle is correctly placed on the platform.
What prevents a driver from weighing twice or lingering on the bridge?
Our software includes empty-scale interlocking. After a transaction saves, the bridge is marked occupied and will NOT accept the same RFID tag or new transaction until the live weight drops below the empty threshold (e.g. 300-500 kg) for several monitoring cycles.
What PLCs are supported for barrier and signal control?
The application includes built-in drivers for industrial PLCs and generic relay controllers.
Convert Your Weighbridge to Unmanned Mode
Integrate UHF RFID readers, PLC position interlocks, and boom barriers with HKDesk software.
